Conveyor Crann Tube
Cur síos
Mar chineál de threalamh iompair leanúnach atá neamhdhíobhálach don chomhshaol, úsáidtear an conveyor crios feadáin ciorclach go príomha le haghaidh iompair guail, gual colúin, cóc, ábhair chumasc, méine sintearach, púdar mianraí, cóc peitriliam, aolchloch, comhiomlán gaineamh gairbhéil, sloda aicéitiléine, deannach humidifying, leasacháin cheimiceach, salann, páipéar dramhaíola, gipseam fosfair, slaig iarainn sulfair agus gach cineál mórchóirí. Tá an prionsabal oibre céanna ag an iompróir crios feadáin ciorclach leis an ngnáthchiorcal crios; is é sin, frithchuimilt a úsáid chun an crios iompair agus a chuid ábhair a aistriú. Is féidir an chuid is mó de na comhpháirteanna a úsáid go coitianta leis an iompróir crios gnáth, áfach, is é an difríocht ná go ndéanfar an crios iompair a rolladh suas sa chruth feadán ciorclach.
Prionsabal agus Struchtúr Conveyor Chreasa Ciorclán Tube:
1. Calafort scaoilte coitianta
2. Calafort a mhuirearú
3. Rannán idirthréimhseach d'ábhair a fhaigheann
4. Téip tubulous speisialta
5. Rannán idirthréimhseach d'ábhar a dhíluchtú
6. Roller Tarchurtha
Nuair a fuair an crios iompair na hábhair ón alt aistrithe ar a eireaball, déanfar an crios iompair a rolladh suas sa chruth feadán ciorclach de réir a chéile, ansin cuirfear an téip feadán ciorclach i bhfeidhm chun iompar na n-ábhar sa bhealach séalaithe a iompar, déanfar an crios iompair a nochtadh de réir a chéile nuair a iompraítear na hábhair go dtí an t-alt trasdula ceann go dtí go n-urscaoileadh na hábhair.
Gnéithe
1. Is féidir leis an chuid is mó ábhar a shéaladh agus a iompar.
2. Is féidir leis na gnáthaimh iompair a shocrú sa bhealach spáis.
3. Is féidir leis an uillinn claonta iompair a fheabhsú.
4. Níl aon fheiniméan gan rianú ann.
5. Is féidir le hábhair a iompar i dhá threo.
Sonraíocht
Trastomhas Tube | Leithead banna | Bandspeed (m / s) | |||||||
0.5 | 0.63 | 0.8 | 1 | 1.25 | 1.6 | 2 | 2.5 | ||
Φ100 | 360 | 10.6 | 13.4 | 17 | 21.2 | 26.5 | 33.9 | 42.4 | 53 |
Φ150 | 550 | 23.9 | 30.1 | 38.2 | 47.7 | 59.6 | 76.3 | 95.4 | 119.3 |
Φ200 | 730 | 42.4 | 53.4 | 67.9 | 84.8 | 106 | 135.7 | 169.6 | 212.1 |
Φ250 | 910 | 66.3 | 83.5 | 106 | 132.5 | 165.7 | 212.1 | 265.1 | 331.3 |
Φ300 | 1100 | 95.4 | 120.2 | 152.7 | 190.9 | 238.6 | 305.4 | 381.7 | 477.1 |
Φ350 | 1280 | 129.9 | 163.7 | 207.8 | 259.8 | 324.7 | 415.6 | 519.5 | 649.4 |
Φ400 | 1460 | 169.6 | 213.8 | 271.4 | 339.3 | 424.1 | 542.9 | 678.6 | 848.2 |
Φ450 | 1640 | 214.7 | 270.5 | 343.5 | 429.4 | 536.8 | 687.1 | 858.8 | 1073.5 |
Φ500 | 1820 | 265.1 | 334 | 424.1 | 530.1 | 662.7 | 848.2 | 1060.3 | 1325.4 |
Φ560 | 2050 | 332.5 | 419 | 532 | 665 | 831.3 | 1064 | 1330 | 1662.5 |
Φ600 | 2190 | 381.7 | 480.9 | 610.7 | 763.4 | 954.3 | 1221.5 | 1526.8 | 1908.5 |
Φ630 | 2300 | 420.8 | 530.2 | 673.3 | 841.7 | 1052.1 | 1346.6 | 1683.3 | 2104.1 |
Φ700 | 2550 | 519.5 | 654.6 | 831.3 | 1039.1 | 1298.9 | 1662.5 | 2078.2 | 2597.7 |
Φ800 | 2900 | 678.6 | 855 | 1085.7 | 1357.2 | 1696.5 | 2171.5 | 2714.3 | 3392.9 |
Φ850 | 3100 | 766.1 | 965.2 | 1225.7 | 1532.1 | 1915.1 | 2451.4 | 3064.2 | 3830.3 |
Trastomhas Tube (mm) | Leithead banna | Bandspeed (m / s) | |||||||
3.15 | 3.55 | 4 | 4.5 | 5 | 5.6 | 6.3 | 7.1 | ||
Φ100 | 360 | 66.8 | 75.3 | 84.8 | 95.4 | 106 | 118.8 | 133.6 | 150.6 |
Φ150 | 550 | 150.3 | 169.4 | 190.9 | 214.7 | 238.6 | 267.2 | 300.6 | 338.8 |
Φ200 | 730 | 267.2 | 301.1 | 339.3 | 381.7 | 424.1 | 475 | 534.4 | 602.2 |
Φ250 | 910 | 417.5 | 470.5 | 530.1 | 596.4 | 662.7 | 742.2 | 835 | 941 |
Φ300 | 1100 | 610.2 | 677.5 | 763.4 | 858.8 | 954.3 | 1068.8 | 1202.4 | 1355 |
Φ350 | 1280 | 818.3 | 922.2 | 1039.1 | 1169 | 1298.9 | 1454.7 | 1636.6 | 1844.4 |
Φ400 | 1460 | 1068.8 | 1204.5 | 1357.2 | 1526.8 | 1696.5 | 1900 | 2137.5 | 2409 |
Φ450 | 1640 | 1352.7 | 1524.4 | 1717.7 | 1932.4 | 2147.1 | 2404.7 | 2705.3 | 3048.9 |
Φ500 | 1820 | 1670 | 1882 | 2120.6 | 2385.6 | 2650.7 | 2968.8 | 3339.9 | 3764 |
Φ560 | 2050 | 2094.8 | 2360.8 | 2660 | 2992.6 | 3325.1 | 3724.1 | 4189.6 | 4721.6 |
Φ600 | 2190 | 2404.7 | 2710.1 | 3053.6 | 3435.3 | 3817 | 4275.1 | 4809.5 | 5420.2 |
Φ630 | 2300 | 2651.2 | 2987.9 | 3366.6 | 3787.5 | 4208.3 | 4713.3 | 5302.4 | 5975.8 |
Φ700 | 2550 | 3273.1 | 3688.7 | 4156.3 | 4675.9 | 5195.4 | 5818.9 | 6546.2 | 7377.5 |
Φ800 | 2900 | 4275.1 | 4817.9 | 5428.7 | 6107.3 | 6785.8 | 7600.1 | 8550.2 | 9635.9 |
Φ850 | 3100 | 4826.2 | 5439 | 6128.5 | 6894.5 | 7660.6 | 8579.8 | 9652.3 | 10878 |
